AK-47 / AK -74 80% receiver jig, both semi and full auto
This complete jig assembly is designed specifically for the 80% AK 47 / AK 74 pre-bent receivers commercially available to Type 07 FFL/Class 2 SOT’s. These also boast the layout for the auto-sear holes for conversion typically by Class II manufacturers into their select-fire counterparts.
This unit accurately locates all fire control drill-in points including the (5) rivet holes for the trigger, plus the (2) auto-sear holes and (3) right side selector switch detents with a modification template for the right side rail required for the select-fire auto sear/bolt interface. The entire pre-assembly completion process may be easily done without making any measurements utilizing only a drill and a Dremel in less than an hour. Bushings protect all drill-in points in the jig for continuous reuse. In addition, these also come with a second bottom plate as well as a 2nd right sideplate for finishing the fire-selector switch horizontal slot. A patent has been applied for (patent pending).
Older version of both AR jigs as well as prior AK jigs
From the photos shown, a unique approach was done to facilitate this via the trigger bottom opening. This design locks the receiver in place for proper alignment of all exterior receiver holes. There is also a receiver insert for complete locking of the alignment as well as being a drilling support and small parts storage. The 7mm and 5mm sized bushings are installed for proper fire control sized holes. A full and complete set of instructions with color 3D CAD drawings are included for the ease of completion. Instructions are attached to the email when the USPS tracking number is sent.
Autosear spring detail
Autosear detail bottom view
If in doubt about the quality of my entire jig lineup, read the remaining comments from the deleted YouTube video from this Reddit link about the AK PRO jig kit
This jig along with all of the others that I design, manufacture, and sell, was “over-engineered” for those who value their time and money. Since I have attempted to foresee and surmount any and all possible errors which could happen during your construction(s), the possibility of your making mistakes approaches zero.
Nothing is more disappointing than a mishap that requires a replacement receiver. Not only is there a monetary loss, but there is also the frustration factor due to the lost time in the work thus far, perhaps a broken tool or fixture, then there is the wait involved for the replacements to arrive from the other supplier via shipping. Now what should have been reasonably fun has become work. Those frustrations only follow my competitors’ sales and not my clients.
I also welcome design requests and if possible will accommodate those in future product revisions. Few other sellers will boast of that.
Jig/template assemblies and supporting parts of the jigs in the photos are included, however (trigger groups or trigger boxes and/or trigger pack assemblies, firearms, receivers, parts, tools, milling bits, and/or drill bits are not included).
This fixture may be lawfully owned by anyone, but ALL NFA RULES APPLY regarding the use of the features incorporated into this product. You (the purchaser) are solely responsible for how this item is used and I (the seller) shall not be held accountable for any misuse of these drilling jigs by you (the purchaser).
Currently I also have a complete 80% AR jig/assembly system, an AR conversion jig, an 80% AR receiver tester, an AK scope mount template, an H&K flat template, a semi to select fire jig for existing HK rifles, and a semi to select-fire conversion jig for the SEF trigger pack which does not corrupt a semi auto receiver, a Class II AK-47/74 / Galil conversion jig for semi to full conversion, a Galil 80% jig, a locked slide conversion (for suppressor use) for the GSG 1911-22 and a Ruger 10-22 80% jig (also with locked bolt drill-in locator) on-line now.
These items are ready to be shipped on the following business day after receipt of funds. Some parts included are either “New or Old Testament Scripture Engraved”, if that offends, please purchase another product from another vendor. My products are made in America, by Americans, for Americans.
Shipping is included.
